Application Scope
Suitable for drying, baking, wax melting and sterilization in industrial and mining enterprises, laboratories, scientific research institutions and other units.
Product Features
- With independently developed core technologies and national patent certificates.
- Adopts the internationally popular streamlined appearance, making the box body more elegant and concise.
- Mirror-finish stainless steel inner chamber with rounded corners at four sides; the shelves are freely adjustable for easy cleaning.
- Adopts microcomputer temperature control, which is accurate and reliable. It can meet various temperature control requirements of users with excellent temperature control accuracy and anti-interference ability.
- The control system is moved to the door, reducing the floor space and weight by 35% without changing the inner chamber dimensions.
- An observation window is installed on the box door, allowing clear observation of the working status inside the chamber.
- The hot air circulation system consists of a low-noise, high-temperature resistant motor and an advanced designed air duct, ensuring uniform temperature and small fluctuation in the working chamber.
- Equipped with a fan stop switch, supporting a wider range of baking products.
- Equipped with a ventilation adjustment knob switch, the air exchange rate between the inside and outside of the chamber can be adjusted through the knob.
- The B-2 series is equipped with a large-screen blue liquid crystal display (LCD) operation interface, and an advanced microcomputer that supports arbitrary on/off time setting and optional timing time ranging from 1 to 9999 minutes, which can meet various temperature control requirements of users.
Optional Accessories (additional charge required)
① RS485 interface ② Printer ③ 30-segment time-sharing temperature controller ④ Additional test hole on the box body
Technical Parameters of Forced Air Drying Oven
| Parameter |
Specification |
| Model |
DGX-9143B-2 |
| Power Supply Voltage |
220V AC, 50Hz |
| Temperature Control Range |
Room temperature +10℃ - 250℃ |
| Temperature Fluctuation |
±1℃ |
| Temperature Accuracy |
0.1℃ |
| Heating Power |
1440W |
| Inner Chamber Dimensions |
550×550×450(mm) |
| External Dimensions |
690×760×580(mm) |
| Shelves (Standard/Maximum) |
2/14 pcs |
