Application Scope
Suitable for drying, baking, wax melting and sterilization in industrial and mining enterprises, laboratories, research institutions and other units.
Product Features
1.Adopts independently developed core technology and has obtained national patent certificates.
2.Uses internationally popular streamlined appearance, making the cabinet more attractive and concise.
3.Mirror-finish stainless steel inner chamber with rounded four corners. Shelves are freely adjustable for easy cleaning.
4.Microcomputer-based temperature control with high accuracy and reliability. Features PID self-tuning and four-digit dual LED display. Excellent temperature control accuracy and anti-interference performance meet various user temperature control requirements.
5.Hot air circulation system consists of low-noise, high-temperature resistant motor and advanced air duct design, ensuring uniform temperature in the working chamber with small fluctuation.
6.Equipped with air exchange adjustment knob to control the rate of air exchange inside and outside the chamber.
7.Series B adopts digital tube display and supports constant temperature timing function from 0 to 999.9 hours.
8.High-quality thermal insulation material ensures excellent heat preservation, stable temperature and low energy consumption during operation.
9.A flowing air interlayer is reserved between thermal insulation material and outer casing to keep the surface temperature of the casing unaffected even at the maximum operating temperature.
Optional Accessories (at extra cost)
- RS485 interface ② Printer ③ 30-segment time and temperature controller ④ Additional test holes on the chamber
Technical Parameters
Model: DGX-8143B
Volume: 140L
Power supply: 220V 50Hz
Timer: 1–9999 minutes
Temperature control range: 50℃ (room temperature) – 400℃
Temperature fluctuation: ±1℃
Heating power: 2300W
Inner chamber dimensions (W×D×H): 550 × 450 × 550 mm
Overall dimensions (W×D×H): 820 × 600 × 720 mm
Shelves (standard / maximum): 2 / 14 pcs
|
Serial No.
|
Category
|
Name
|
Unit
|
Quantity
|
Remarks
|
|
1
|
Document
|
Operation Manual copy
|
Copy
|
1
|
|
|
2
|
Document
|
Packing List
|
Copy
|
1
|
|
|
3
|
Document
|
Certificate of Conformity
|
Copy
|
1
|
|
|
4
|
Document
|
Fuse piece
|
Pc
|
2
|
|
|
5
|
Document
|
User Feedback Card copy
|
Copy
|
1
|
|
