Features:
■ Advanced peltier-based semiconductor technology.
■ High performance global universal power supply.
■ 5.7-inches high definition LCD screen.
■ Curve graphics interface in English & Chinese.
■ Data protection function while power failure.
■ Metal shell with stability ,practicability ,& beautiful generous appearance.
■ Adjustable hot lid can use test tube with different height.
■ Hot lid can be positioned at arbitrary angle.
■ High-sealing reaction area can ensure experiment stability & reliability.
Specification:
| Item |
DL9700 GENARAL |
DL9700 GRADIENT |
| Capacity |
96×0.2ml , 96×0.2ml+77×0.5ml , 54×0.5ml , 384well |
| Temperature Range |
0~99.9℃ |
| Heating Rate |
4℃/s |
| Cooling Rate |
3℃/s |
| Uniformity |
≤±0.3℃ |
| Accuracy |
≤±0.2℃ |
| Display Resolution |
0.1℃ |
| Temperature Control |
Block\Tube |
| Ramping Rate Adjustale |
0.1~2.5℃ |
| Gradient Uniformity |
/ |
≤±0.3℃ |
| Gradient Accuracy |
/ |
≤±0.2℃ |
| Gradient Temp. Range |
/ |
30~99.9℃ |
| Gradient Spread |
/ |
1~30℃ |
| Hot Lid Temperature |
30~110℃ |
| Hot Lid Height Adjustale |
Stepless Adjustable |
| Number of Programs |
200 |
| Max.No.of Segment |
9 |
| Max.No.of Step |
9 |
| Max.No.of Cycle |
99 |
| Time Increment/Decrement |
1 Sec ~ 9 Min 59 Sec |
| Temp. Increment/Decrement |
0.1~9.9℃ |
| Pause Funcation |
Yes |
| Auto Data Protection |
Yes |
| Graphical Display |
Yes |
| Hold at 4℃ |
Forever |
| Language |
Englis/Chinese |
| LCD |
5.7inch,320×240 pels |
| Communication |
USB2.0 , RS232 |
| Dimensions |
392mm×262mm×252mm (L×W×H) |
| Weight |
10kg |
| Power Supply |
85~264VAC , 50~60Hz , 600 W |
